Product Features

•
  01 Simple & Developer-Friendly VR Data Glove

  No calibration needed – the glove is ready to use out of the box, having been paired and calibrated at the factory in under a minute. It also provides SDKs for Unity3D, UE4, MotionBuilder, and C++, with open-source interactive scenarios, sample code, comprehensive documentation, and demo videos. Wrist tracking supports mainstream positioning solutions like Vicon, OptiTrack, Qingtong Vision, Nokov, Ruili Vision RTS, and HTC VIVE Tracker.

•
  02 High Frame Rate, Low Latency Motion Capture

  Real-time acquisition of finger joint data using high-performance 9-axis MEMS inertial sensors across the hand, with inverse kinematics to reconstruct skeletal movements in virtual environments. An integrated palm vibration feedback module triggers contextual haptic effects, enhancing immersion. The glove employs 2.4GHz wireless transmission to achieve over 120Hz per hand with latency under 10ms.

•
  03 Extended Battery Life & Unnoticeable Wear

  Featuring ultra-low power consumption and extended standby, each glove is powered by a 1200mAh rechargeable lithium battery for over 20 hours of continuous work. Crafted with lightweight fabric and compact inertial sensors, the glove feels virtually unnoticeable, ensuring comfort and freedom during prolonged use.

• 04 Demonstration Video

  If the video does not autoplay, click here to view it on an external link

Product Specifications

•
  Hand Motion Capture

  Inertial sensors on each of the five fingers provide 3DOF dynamic posture data, while a sensor on the back of the hand accurately detects wrist rotation.

•
  High-Speed Wireless Transmission

  The data glove is completely cable-free with a transmission latency of less than 10ms, offering a highly immersive VR experience.

•
  Wrist Motion Tracking

  Easily extend compatibility with mainstream tracking solutions including Vicon, OptiTrack, Qingtong Vision, Nokov, Ruili Vision RTS, and HTC VIVE Tracker.

•
  Motion Sensor Fusion Algorithm

  Our self-developed high-precision 9-axis sensor fusion algorithm with integrated geomagnetic calibration guarantees stable and accurate motion data capture.

•
  2.4GHz Interference-Resistant Wireless Communication

  The wireless signal processing and transmission module features an efficient interference-resistant auto-frequency hopping algorithm, ensuring stable performance even in complex environments.

•
  Exceptional Battery Life

  Each sensor’s peak consumption is under 8mA, and the data processing unit is optimized for low power, guaranteeing at least 20 hours of continuous operation.

Applicable scenarios: VR training, VR entertainment, industrial simulation requiring high precision in finger movements, as well as full-body motion capture integration for film and animation production.

VRTRIX™ Data Glove continuously provides and updates its developer SDK and plugins, including Unity3D and UE4 plugins, MotionBuilder plugin, and a C++ SDK. If the links below do not open, please visit the Baidu Netdisk mirror to obtain the latest software and documentation. Baidu Netdisk Mirror (access code: 8r8w)
